MOSTARNA CZECH

In cooperation with the company Lískovec MOSTÁRNA we primarily provide the production of steel bridges and structures.
We also participate in the production of engineering parts for the mining and processing industries.

Reference

Project: Mainbrücke Horhausen - Arch bridge

Production of 2 pieces of closed steel beams VT1-W and VT5-W with a total weight of about 77.7 tons.

Production of 4 pieces of bridge steel arches B1-W, B2-W, B2-O and B5-W with a total weight of 132 tons.

Construction: D48 Frýdek-Místek, bypass - II. phase

Building SO 222 Bridge on the crossroads branch MUK Dobrá km 8.118

Description: The load-bearing steel structure of the bridge is a chamber girder with three bays, where each field is divided into three segments and the spans of individual bays are 33 m + 47 m + 33 m. The weight of this steel bridge structure is 238 tons and is classified according to ČSN EN 1090-2 + A1.

Construction: D48 Frýdek-Místek, bypass - II. phase

Building object: SO 217 - Bridge over the Morávka in km 6.205

Description: The bridge is the largest bridge object in the R48 construction of the Frýdek - Místek bypass.

Each conveyor belt has its own load-bearing steel structure, where the left and right parts of the bridge consist of a pair of full-walled beams, connected by support beams and cross braces. The sum of the field spans is 426 m and the total weight of the steel structures is 3,237 tons. The steel structure of the bridge is included in the EXC3 design class according to ČSN EN 1090-2 + A1.
